Part Number: XLIT997MA Compatibility: 2016-2020 Lexus GS-F Chassis code: URL10
Preset Approximate Height
Front: -20mm to -25mm (-0.8in to -1.0in) Rear: -20mm to -25mm (-0.8in to -1.0in)
Maximum Adjustment Range
Front: +25mm to -75mm (+1.0in to -3.0in) Rear: +5mm to -40mm (+0.2in to -1.6in)
Recommended Adjustment Range
Front: +5mm to -50mm (+0.2in to -2.0in) Rear: +5mm to -40mm (+0.2in to -1.6in)
Spring Rate
Front: 10.00kg/mm Rear: 14.00kg/mm
Additional Information
Dampers are 36 way adjustable in the front and the rear Warranty: 1 Year / 12,000miles from the day of purchase. Included but not pictured: hex and allen wrench, nut and spring washer for rear, ABS bracket stay (rubber, bolt and washer), AVS harness ASSY for front and rear, zip tie for front and rear, corrugate tube for front, grommet for rear harness
